Pilot Retort

The pilot retort autoclave is for purpose of testing food sterilization recipe, esp.for new developed products. It can be customized according to your demand.

Category：

Batch Retort Autoclave

Hotline：

+86-18678074551

Email:

lindasheng@zlphretort.cn

Related Products

Enquiry

Description
Working principle
Parameter
Video

- Commodity name: Pilot Retort
- Commodity ID: 1078690929146744832
The pilot retort autoclave is for purpose of testing food sterilization recipe, esp.for new developed products. It can be customized according to your demand.

1.This equipment is specially designed for product development laboratory to develop the sterilization process of new products.

2.Simulated the sterilizing environment in actual production to test the F0 value and make an effective sterilization formula for mass production, thus to reduce the loss of products in experiment and improve the yield of the target/standard production.

3.The heating mode: steam direct heating and indirect heating， electric heating.

4.Pilot Lab retort special for enterprises, teaching and scientific research, with diversified heating methods (steam, electricity, or both);

5.With F0 value function, not only test and record the F0 value of the product;

6.The sterilization effect is intuitive, controllable，without deviation;

7.High precision of automatic program control, real-time monitoring of temperature and pressure throughout the process。

8.The sterilization method：water spray, water immersion, steam

9.Sterilization status: static and rotary.

Application Products
Key words:
- Pilot Retort
1.Combine complex sterilization methods such as steam, water bath, spray, and rotation;

2.Steam sterilization directly uses steam to heat the product, and the cold water directly cools down;

3.Water bath sterilization, the product is completely immersed in water, using water as a medium to heat the product, cool water directly cool down;

4.Spray sterilization, with a small amount of sterilization process water, through the nozzle atomization to heat the product, the heat exchanger indirectly cools;

5.Terilization requirements;

6.Independent manual operation panel, convenient for manual and emergency treatment.

Model	Dia.	Chamber length	Total L.	Total W.	Total H.	Vol.	Steam consumption	Power	Trolley	Basket	Design temp.	Design P.	Test P.
Model	（mm）	（mm）	（mm）	（mm）	（mm）	（m³）	（kg）	（KW）	（Stack）	（pcs）	（℃）	（MPa）	（MPa）
ZLPH/SYF700	700	500	1850	1200	1850	0.28	15	2.1	-	1	147	0.35	0.44
ZLPH/SYF900	900	600	2200	1700	2100	0.56	25	4	-	1	147	0.35	0.44
