Rotary Steam Retort Autoclave Sterilizer

Rotary steam retort autoclave is used for viscous food in tin cans like evaporated milk, porridge coconut milk etc.. Its rotation makes food move in container while the its rotation body moves around, which is good sterilization effect and taste.

Category：

Batch Retort Autoclave

Hotline：

Email:

lindasheng@zlphretort.cn

Related Products

Enquiry

Description
Working principle
Parameter
Video

- Commodity name: Rotary Steam Retort Autoclave Sterilizer
- Commodity ID: 1078690978975076352
Rotary steam retort autoclave is used for viscous food in tin cans like evaporated milk, porridge coconut milk etc.. Its rotation makes food move in container while the its rotation body moves around, which is good sterilization effect and taste.

1. When rotating and heating up, the heat quickly penetrates the product to achieve the required sterilization effect and F0 value;
2. The external supporting wheels are integrated with the cylinder support, and the retort body is equipped with a protective plate, which can extend the life and make repairs and maintenance more convenient;
3. The rotating body adopts forged rolling rings, and the whole body is treated with aging treatment to enhance toughness, plasticity, wear resistance and prolong service life;
4. After welding and assembling, the rotating body is processed and formed by a machining center at one time. After dynamic balancing, the concentricity of the axis and the rotating body is ensured during the rotation process, and the phenomenon of heavy rotation is avoided;
5. The automatic compression system uses cylinders to compress separately, and the entire cylinder is made of alloy, which solves the problems of inaccurate spring reset and the deformation of the cylinder seal under high temperature and high pressure.
6. Frequency conversion speed regulation, the user can adjust the rotation speed at any time according to the product characteristics;
7. Automatic positioning function to ensure that the cage is in a horizontal position after stopping, which is convenient for smooth docking with other supporting equipment;
Application Products
Key words:
- Rotary Steam Retort Autoclave Sterilizer
Similar to steam retort， there are two ways to drive cold air out of retort: by hot water or by steam.
1. Drive cold air by hot water
(1) This way requires retort to be with a hot water tank;
(2) Load products into retort, close the door, and pour hot water from the upper tank into retort through the water pump;
(3) Hot water enters retort from its bottom and fills full of the entire chamber;
(4) Then steam is injected into the retort from its top to press the hot water back into the upper tank;
(5) After hot water is recovered, steam injection at the top is changed to from the bottom of retort instead;
(6) When the come-up stage starts, use a proportional valve to control the amount of steam injected into retort until the target sterilization temperature;
(7) In the sterilization stage, the temperature and pressure in retort are accurately controlled through automatic valves;
(8) Cooling water injected into retort through a cold water pump to cool down the product inside.
2. Driving cold air by steam
(1) Not requires hot water tank
(2) The retort is filled full of steam from the bottom to remove the cold air ;
(3) Proportional valve to control the injection of steam from the bottom, and open the large exhaust at the top to remove the cold air;
(4) In come-up stage, the proportioinal valve control the steam amount to reach the set sterilization temperature;
(5) In the sterilization stage, the temperature and pressure in the retort can be accurately controlled through automatic valves;
(6) Cooling water is injected into retort through a cold water pump to cool down products inside.

Model	Dia.	Drum Length	Total Length	Total Width	Total Height	Vol.	Steam consumption	Power	Basket/Tray	Design Temp.	Design P.	Test P.
Model	（mm）	（mm）	（mm）	（mm）	（mm）	（m³）	（kg）	（kw）	（pcs）	（℃）	（Mpa）	（Mpa
ZLPH/XZ1500-4K	1500	4500	6000	2500	2500	8.3	300	12	4	147	0.35	0.44
ZLPH/XZ1800-4K	1800	5100	6800	3000	3100	13.6	350	15	4
ZLPH/XZ1800-5K	1800	6300	8000	3000	3100	16.7	420	20	5
ZLPH/XZ1800-6K	1800	7300	9000	3000	3100	19.2	500	24	6
